Step Down DC Converter

Step Down DC Converter
Step Down DC Converter
Step Down DC Converter

Step Down DC Converter

Default
Regular price $6.99
/
  • Free shipping on all orders over $100
  • Secure payments
  • In stock, ready to ship
  • Inventory on the way
Tax included. Shipping calculated at checkout.

Package Included
- 1pcs x XL7015 DC-DC Dc converter Step-down module 5V-80V Wide voltage input to 5V~20V output

Description:
1. 5V to 80V wide input voltage range;
2. The output voltage is adjustable from 5V to 20V;
3. The minimum pressure drop 1V;
4. The maximum switching current of 0.8A;
5. Recommended output power less than 7W;
6. Built-in thermal shutdown protection, output short circuit protection, overcurrent protection;
7. The excellent linearity and load regulation;


Wiring
1. VIN: input voltage (5V-80V);
2. GND: the input voltage ground terminal;
3. VOUT: Output voltage terminal (5V-20V);
4. GND: output voltage of the ground terminal;

Note:
- Output current can not be adjust.
- The input voltage should not exceed the maximum input voltage.
- There could be a maximum output voltage difference of around 5%.
